PRO 330 DX
Click on picture for enlargement
PRO Series
Medium type
FOR USE WITH
DESCRIPTION
SLIK Super Alloy (A.M.T.) for the first (23.4mm) and the second (20mm) pipes with light weight panhead SH-705E 3-way with 2 pan & tilt handles for easy operation.

with 3-way panhead SH-705E
SPECIFICATIONS
Folded Length: 600mm
Maximum Operating Height: 1,592mm
Minimum Operating Height: 294mm
Maximum Center Column Ext.: 350mm
Weight: 1,690g
Head Portion Weight: 450g
Leg Portion Weight: 1,240g
Leg Lock Type: S.R.L.
Leg Tip: Rubber
How To Mount Camera: Q.R.S.
Number of Leg Sections: 3
Shape of Leg Pipe/Tube:
Diameter of the first upper leg: 23.4mm
Type of Center Column Elevation: Center column type
Panhead: -
Type of Bubble Level: Single bubble level
Special Features: Multi-position leg
KEY TECHNOLOGY
MADE OF SLIK SUPER ALLOY A.M.T.
(Aluminum-Magnesium-Titanium alloy)
SLIK A.M.T. Alloy offers an exceptional strength-to-weight ratio more than 40% greater than similar tripods. (except PRO 400DX & ABLE 300DX)

GROOVED TUBULAR LEGS
The groove, in the already dynamically strong circular tubing, prevents the leg from spinning around, and allows simple and secure locking. It also allows you to extend the leg from any section, regardless of the order. (except PRO 400DX & ABLE 300DX)
GEARLESS, DETACHABLE & INVERTIBLE CENTER COLUMN
Just loosen locking collar, and pull up. Camera height and direction can be adjusted in one motion. For extremely low angle positioning without changing an optional center column.

3-POSITION LEG ANGLE ADJUSTMENT
Choice of three different leg angles for quick set up on inclined, or uneven ground.
